import os
os.environ['__NV_PRIME_RENDER_OFFLOAD'] = '1'
os.environ['__GLX_VENDOR_LIBRARY_NAME'] = 'nvidia'
import numpy as np
from OpenGL.GL import *
from OpenGL.GL import shaders
from OpenGL.GLU import *
import pygame
# 버텍스 쉐이더
VERTEX_SHADER = """
#version 330 core
layout(location = 0) in vec3 position;
layout(location = 1) in vec3 normal;
uniform mat4 model;
uniform mat4 view;
uniform mat4 projection;
out vec3 FragPos;
out vec3 Normal;
void main()
{
FragPos = vec3(model * vec4(position, 1.0));
Normal = mat3(transpose(inverse(model))) * normal;
gl_Position = projection * view * model * vec4(position, 1.0);
}
"""
# 프래그먼트 쉐이더 수정
FRAGMENT_SHADER = """
#version 330 core
in vec3 FragPos;
in vec3 Normal;
uniform vec3 lightPos;
uniform vec3 viewPos;
uniform vec3 lightColor;
uniform vec3 objectColor;
out vec4 FragColor;
void main()
{
// 주변광 세기 증가
float ambientStrength = 0.4;
vec3 ambient = ambientStrength * lightColor;
// 분산광 (디퓨즈)
vec3 norm = normalize(Normal);
vec3 lightDir = normalize(lightPos - FragPos);
float diff = max(dot(norm, lightDir), 0.0);
vec3 diffuse = diff * lightColor;
// 반사광 (스페큘러) 추가
float specularStrength = 0.5;
vec3 viewDir = normalize(viewPos - FragPos);
vec3 reflectDir = reflect(-lightDir, norm);
float spec = pow(max(dot(viewDir, reflectDir), 0.0), 32);
vec3 specular = specularStrength * spec * lightColor;
vec3 result = (ambient + diffuse + specular) * objectColor;
FragColor = vec4(result, 1.0);
}
"""
class ModernModelViewer:
def __init__(self, model_path):
pygame.init()
# OpenGL 설정
pygame.display.gl_set_attribute(pygame.GL_MULTISAMPLEBUFFERS, 1)
pygame.display.gl_set_attribute(pygame.GL_MULTISAMPLESAMPLES, 4)
pygame.display.gl_set_attribute(pygame.GL_DEPTH_SIZE, 24)
pygame.display.gl_set_attribute(pygame.GL_STENCIL_SIZE, 8)
self.display = pygame.display.set_mode((800, 600),
pygame.OPENGL |
pygame.DOUBLEBUF |
pygame.HWSURFACE)
pygame.display.set_caption("3D Model Viewer (Modern OpenGL)")
# 모델 데이터 로드
self.vertices, self.faces, self.normals = self.load_obj(model_path)
# 변환 행렬 초기화
self.model_matrix = np.identity(4, dtype=np.float32)
self.view_matrix = np.identity(4, dtype=np.float32)
self.projection_matrix = self.perspective(45, 800/600, 0.1, 100.0)
# 카메라/뷰어 상태
self.camera_pos = np.array([0.0, 2.0, 5.0], dtype=np.float32) # z축 거리를 늘리고 y축으로 올립니다
self.rotation = np.array([30.0, 0.0, 0.0]) # x축으로 30도 회전하여 모델을 내려다보게 합니다
self.scale = 1.0
# 마우스 제어 관련 속성 추가
self.dragging = False
self.prev_mouse_pos = None
self.mouse_sensitivity = 0.8
# 쉐이더 프로그램 생성
self.shader = self.create_shader_program()
# VAO, VBO 설정
self.setup_vertex_buffer()
# FPS 제어
self.clock = pygame.time.Clock()
self.target_fps = 144
def perspective(self, fovy, aspect, near, far):
"""원근 투영 행렬 생성"""
f = 1.0 / np.tan(np.radians(fovy) / 2.0)
return np.array([
[f/aspect, 0.0, 0.0, 0.0],
[0.0, f, 0.0, 0.0],
[0.0, 0.0, (far+near)/(near-far), 2*far*near/(near-far)],
[0.0, 0.0, -1.0, 0.0]
], dtype=np.float32)
def create_shader_program(self):
"""쉐이더 프로그램 컴파일 및 링크"""
try:
vertex_shader = shaders.compileShader(VERTEX_SHADER, GL_VERTEX_SHADER)
print("Vertex shader compiled successfully")
fragment_shader = shaders.compileShader(FRAGMENT_SHADER, GL_FRAGMENT_SHADER)
print("Fragment shader compiled successfully")
shader_program = shaders.compileProgram(vertex_shader, fragment_shader)
print("Shader program linked successfully")
# 쉐이더 프로그램 검증
glValidateProgram(shader_program)
validation_status = glGetProgramiv(shader_program, GL_VALIDATE_STATUS)
print(f"Shader program validation status: {validation_status}")
if validation_status != GL_TRUE:
print(glGetProgramInfoLog(shader_program))
return shader_program
except Exception as e:
print(f"Error creating shader program: {str(e)}")
raise
def load_obj(self, filename):
"""OBJ 파일 로드 및 법선 벡터 계산"""
vertices = []
faces = []
normals = []
try:
with open(filename, 'r') as f:
for line in f:
if line.startswith('v '):
parts = line.split()
if len(parts) >= 4: # v x y z 형식인지 확인
vertices.append([float(parts[1]), float(parts[2]), float(parts[3])])
elif line.startswith('f '):
face = []
parts = line.split()[1:] # 첫 번째 'f' 제외
for part in parts:
# 빈 줄이나 잘못된 형식 건너뛰기
if '/' in part:
vertex_index = part.split('/')[0]
if vertex_index:
face.append(int(vertex_index) - 1)
if len(face) >= 3: # 최소 3개의 유효한 인덱스가 있는지 확인
faces.append(face)
if not vertices or not faces:
raise ValueError("No valid vertices or faces found in the file")
vertices = np.array(vertices, dtype=np.float32)
faces = np.array(faces, dtype=np.int32)
# 모델 중심을 원점으로 이동
center = (vertices.max(axis=0) + vertices.min(axis=0)) / 2
vertices -= center
# 모델 크기를 1로 정규화
scale = np.max(np.abs(vertices))
if scale != 0:
vertices /= scale
# 버텍스 법선 계산
normals = np.zeros_like(vertices)
for face in faces:
if len(face) >= 3: # 안전 검사 추가
v1, v2, v3 = vertices[face[0]], vertices[face[1]], vertices[face[2]]
normal = np.cross(v2 - v1, v3 - v1)
norm = np.linalg.norm(normal)
if norm > 1e-6:
normal = normal / norm
normals[face] += normal
# 법선 벡터 정규화
norms = np.linalg.norm(normals, axis=1)
norms[norms == 0] = 1
normals = normals / norms[:, np.newaxis]
print(f"Loaded model with {len(vertices)} vertices and {len(faces)} faces")
return vertices, faces, normals
except Exception as e:
print(f"Error loading OBJ file: {str(e)}")
print(f"Current working directory: {os.getcwd()}")
print(f"Trying to load file: {filename}")
return np.array([]), np.array([]), np.array([])
def update_matrices(self):
"""변환 행렬 업데이트"""
# 모델 행렬
model = np.identity(4, dtype=np.float32)
# 회전 적용
rx = self.rotation_matrix(self.rotation[0], [1, 0, 0])
ry = self.rotation_matrix(self.rotation[1], [0, 1, 0])
rz = self.rotation_matrix(self.rotation[2], [0, 0, 1])
model = model.dot(rx).dot(ry).dot(rz)
self.model_matrix = model
# 뷰 행렬
target = np.array([0.0, 0.0, 0.0])
up = np.array([0.0, 1.0, 0.0])
self.view_matrix = self.look_at(self.camera_pos, target, up)
def rotation_matrix(self, angle, axis):
"""회전 행렬 생성"""
angle = np.radians(angle)
axis = np.array(axis) / np.linalg.norm(axis)
a = np.cos(angle / 2.0)
b, c, d = -axis * np.sin(angle / 2.0)
return np.array([
[a*a+b*b-c*c-d*d, 2*(b*c-a*d), 2*(b*d+a*c), 0],
[2*(b*c+a*d), a*a+c*c-b*b-d*d, 2*(c*d-a*b), 0],
[2*(b*d-a*c), 2*(c*d+a*b), a*a+d*d-b*b-c*c, 0],
[0, 0, 0, 1]
], dtype=np.float32)
def look_at(self, eye, target, up):
"""뷰 행렬 생성"""
eye = np.array(eye, dtype=np.float32)
target = np.array(target, dtype=np.float32)
up = np.array(up, dtype=np.float32)
# z axis = eye - target (normalized)
z = eye - target
z = z / np.linalg.norm(z)
# x axis = up cross z (normalized)
x = np.cross(up, z)
if np.sum(x) == 0: # 'up' 벡터와 'z' 벡터가 평행한 경우 처리
x = np.array([1.0, 0.0, 0.0], dtype=np.float32)
else:
x = x / np.linalg.norm(x)
# y axis = z cross x (normalized)
y = np.cross(z, x)
y = y / np.linalg.norm(y)
translation = np.array([
[1, 0, 0, -eye[0]],
[0, 1, 0, -eye[1]],
[0, 0, 1, -eye[2]],
[0, 0, 0, 1]
], dtype=np.float32)
rotation = np.array([
[x[0], x[1], x[2], 0],
[y[0], y[1], y[2], 0],
[z[0], z[1], z[2], 0],
[0, 0, 0, 1]
], dtype=np.float32)
return rotation.dot(translation)
def setup_vertex_buffer(self):
"""VAO와 VBO 설정"""
try:
self.vao = glGenVertexArrays(1)
glBindVertexArray(self.vao)
# 모든 버텍스 데이터를 하나의 배열로 준비
vertices = []
for face in self.faces:
for vertex_id in face:
vertex = self.vertices[vertex_id]
normal = self.normals[vertex_id]
vertices.extend([*vertex, *normal]) # [x,y,z, nx,ny,nz]
vertices = np.array(vertices, dtype=np.float32)
self.vertex_count = len(self.faces) * 3
# VBO 생성 및 데이터 업로드
self.vbo = glGenBuffers(1)
glBindBuffer(GL_ARRAY_BUFFER, self.vbo)
glBufferData(GL_ARRAY_BUFFER, vertices.nbytes, vertices, GL_STATIC_DRAW)
# vertex positions
glEnableVertexAttribArray(0)
glVertexAttribPointer(0, 3, GL_FLOAT, GL_FALSE, 24, None)
# vertex normals
glEnableVertexAttribArray(1)
glVertexAttribPointer(1, 3, GL_FLOAT, GL_FALSE, 24, ctypes.c_void_p(12))
# 디버그 출력
print(f"Vertex count: {self.vertex_count}")
print(f"Vertex data size: {vertices.nbytes} bytes")
except Exception as e:
print(f"Error in setup_vertex_buffer: {str(e)}")
raise
def render_model(self):
try:
glClearColor(0.1, 0.1, 0.1, 1.0)
glClear(GL_COLOR_BUFFER_BIT | GL_DEPTH_BUFFER_BIT)
glEnable(GL_DEPTH_TEST)
glEnable(GL_MULTISAMPLE)
glEnable(GL_LINE_SMOOTH)
glEnable(GL_POLYGON_SMOOTH)
glHint(GL_LINE_SMOOTH_HINT, GL_NICEST)
glHint(GL_POLYGON_SMOOTH_HINT, GL_NICEST)
glUseProgram(self.shader)
self.update_matrices()
# 조명 설정
glUniform3f(glGetUniformLocation(self.shader, "lightPos"), 3.0, 5.0, 3.0)
glUniform3f(glGetUniformLocation(self.shader, "viewPos"), *self.camera_pos)
glUniform3f(glGetUniformLocation(self.shader, "lightColor"), 1.0, 1.0, 0.95)
glUniform3f(glGetUniformLocation(self.shader, "objectColor"), 0.9, 0.9, 0.9)
# 행렬 전송
glUniformMatrix4fv(glGetUniformLocation(self.shader, "model"), 1, GL_TRUE, self.model_matrix)
glUniformMatrix4fv(glGetUniformLocation(self.shader, "view"), 1, GL_TRUE, self.view_matrix)
glUniformMatrix4fv(glGetUniformLocation(self.shader, "projection"), 1, GL_TRUE, self.projection_matrix)
# 모델 렌더링
glBindVertexArray(self.vao)
glDrawArrays(GL_TRIANGLES, 0, self.vertex_count)
pygame.display.flip()
except Exception as e:
print(f"Render error: {str(e)}")
def run(self):
"""메인 렌더링 루프"""
while True:
try:
# 이벤트 처리
for event in pygame.event.get():
if event.type == pygame.QUIT:
return
elif event.type == pygame.KEYDOWN:
if event.key == pygame.K_ESCAPE:
return
# 마우스 입력 처리 추가
elif event.type == pygame.MOUSEBUTTONDOWN:
if event.button == 1: # 왼쪽 버튼
self.dragging = True
self.prev_mouse_pos = pygame.mouse.get_pos()
elif event.type == pygame.MOUSEBUTTONUP:
if event.button == 1: # 왼쪽 버튼
self.dragging = False
elif event.type == pygame.MOUSEMOTION:
if self.dragging:
x, y = pygame.mouse.get_pos()
if self.prev_mouse_pos:
dx = x - self.prev_mouse_pos[0]
dy = y - self.prev_mouse_pos[1]
self.rotation[2] -= dx * self.mouse_sensitivity # z축 회전으로 변경
self.rotation[0] -= dy * self.mouse_sensitivity # x축 유지
self.prev_mouse_pos = (x, y)
self.render_model()
self.clock.tick(self.target_fps)
except Exception as e:
print(f"Error during rendering: {str(e)}")
break
pygame.quit()
# 리소스 정리
glDeleteVertexArrays(1, [self.vao])
glDeleteBuffers(1, [self.vbo])
glDeleteProgram(self.shader)
if __name__ == "__main__":
import sys
import os
if len(sys.argv) > 1:
model_path = sys.argv[1]
else:
model_path = "12221_Cat_v1_l3.obj" # "Tree.obj"
# 파일 존재 여부 확인
if not os.path.exists(model_path):
print(f"Error: File '{model_path}' does not exist")
sys.exit(1)
try:
viewer = ModernModelViewer(model_path)
viewer.run()
except Exception as e:
print(f"Error: {str(e)}") |
